The original Adapter board to make connecting a filament sensor or BL Touch painless to your printer.
Wide power traces with 2oz Copper PCB, Firmware Included via Download
NOTE: A bootloader required to update firmware flash your bootloader with an Uno.
From: $7.99
Why do you want this upgrade?
If you get the EZOut board you will be using this to connect a BL Touch ABL sensor to your 3D Printer. You plug this board into your LCD header on your control board and then plug the LCD cable into our board. You then have the required 5V, Ground, and Signal pins available to connect to your BL Touch Sensor with ZERO soldering. The signal pin broken out on our board is Pin 27, this will be your SERVO pin in your firmware.
Installation Links
Use our new Unified 2.0 Firmware and follow our setup guide for the BLTouch here: Unified Firmware – BLTouch Settings
Bootloader Required
You can add on a bootloader kit above and there is a very easy to follow guide with a video on our page here: 1284p Printer Bootloader Flashing Video Guide – CR-10/Ender 2 3 5/Wanhao i3/Anet
FAQ
| Weight | 4 oz |
|---|---|
| Dimensions | 6 × 6 × 2 in |
| Made In | 🇨🇳 China w/QC in 🇺🇸 USA |
| Warranty Length | 6 Months |
