EZOut BLTouch Adapter Board for Ender 5/5 Pro – V1.1.X Boards

The original Adapter board to make connecting a filament sensor or BL Touch painless to your printer.

Wide power traces with 2oz Copper PCB, Firmware Included via Download

NOTE: A bootloader required to update firmware flash your bootloader with an Uno.

From: $7.99

1 user has this item in wishlist

Don't have a bootloader on your board?

Add on our easy to use bootloader kit to flash your bootloader.

Out of stock

Description

Why do you want this upgrade?

If you get the EZOut board you will be using this to connect a BL Touch ABL sensor to your 3D Printer. You plug this board into your LCD header on your control board and then plug the LCD cable into our board. You then have the required 5V, Ground, and Signal pins available to connect to your BL Touch Sensor with ZERO soldering. Recommended BL Touch Installation Information: https://www.thingiverse.com/thing:2975949

Ender 3/Ender 5 BL Touch Notes:

If using with a BL Touch you can use a 3 Pin JST plug to connect to our board or dupont connectors (Ender 3 may be a tight fit due to the lid with dupont connectors). No cables are included with the board only version for BL Touch use. JST 3 Pin Example: https://amzn.to/2RDnj2w


Installation Links

EZOut Installation Guide

Use our new Unified 2.0 Firmware and follow our setup guide for the BLTouch here: Unified Firmware – BLTouch Settings


Bootloader Required

You can add on a bootloader kit above and there is a very easy to follow guide with a video on our page here: 1284p Printer Bootloader Flashing Video Guide – CR-10/Ender 2 3 5/Wanhao i3/Anet


FAQ

  • Why is there a pin missing on the header?
    • This is removed so the pin does not connect to the LCD after installation and is completely normal.
  • Is a BLTouch Included?
    • No, this is just for our adapter PCB. BLTouch sold separately.

Additional information

Don't have a bootloader on your board?

Weight 4 oz
Dimensions 6 × 6 × 2 in
Made In

🇨🇳 China w/QC in 🇺🇸 USA

Warranty Length

6 Months
