EZNeo 5V Universal Power Kit

2 reviews

Provides up to 1A output at 5V. Perfect for powering the EZNeo Strips. The module is very small (~20mm x ~5mm) and heat-shrunk to stash virtually anywhere.

NEW – Don’t want to solder at all? Use a heat gun and pick up a pack of our Quick Solder connectors here -> Quick Solder Wire Connectors (22-26 AWG) – 5 Pack – Solder Seals

$4.99

7 users have this item in wishlist

In stock

Description

What is this for?

This is for powering our EZNeo strips from your printer power supply. This is a universal power module that converts your printer’s 12-24V power supply voltage to the 5V that the EZNeo strips need. The max power output of this module is 1A. The power is pre-set so NO adjustment is needed, just wire it up and update your firmware to tell it that you have the EZNeo installed. You will need to solder 2 wires to install this on your printer (see the documentation below for details).

Male to female jumper wires are included (10x). Color and length will vary depending on stock.

This is ONLY for our EZNeo strips, do NOT power a Raspberry Pi from this as it does not have enough output to power a Pi.


Wiring Info

The guide on how to assemble the wiring with this adapter are located here: EZNeo – 5V Universal Power Kit Documentation – TH3D Studio LLC

See our Help Center section for the EZNeo strips here for board-specific wiring information: EZNeo Lighting Kits – TH3D Studio LLC

Plug ends – Input is a Male JST RCY and output is a Female JST SH 1.0mm. Jumper wires to connect to the INPUT side are included and the signal wire. The jumpers allow for installation without cutting the EZNeo cable. The output side will need to be clipped and soldered to the included jumpers.

Additional information

Weight 2 oz
Dimensions 1 × 1 × 0.5 in
Made In

🇨🇳 China w/QC in 🇺🇸 USA

Warranty Length

6 Months
