- Made with actual rubber, not plastic or PU like some other belts
- Excellent grip and wear resistance
- Works with most 3D printers that use belt including but not limited to:
- Creality 3D Printers (S4 and S5 use 10mm width on Y, this is 6mm)
- Anet Machines 3D Printers
- TronXY 3D Printers
- Wanhao 3D Printers
- Geeetech 3D Printers
- Alfawise 3D Printers
- Tevo 3D Printers
- Install Notes:
- When replacing a belt cut the new belt to the length of the old belt.
- If your printer used crimped ends on the original belts cut the new belt 30-40mm longer.
- Wrap the end of the belt around the belt attachment point on your carriage and fold it onto itself so the teeth mesh.
- Then use 2x small zip ties to keep the teeth forced together and trim the excess belt length off.
- Keep the zip ties as close to the attachment point as possible and make sure the ties will not hit anything during movement.
- Reinforced with 8+ internal fiber strands for durability and stretch resistance
- Specs
- Width: 6mm
- Pitch: 2mm
- Type: 2GT
- Sold by the meter
- When ordering more than 1 meter it will be one continuous length
Warranty Information
3 Months Warranty - Our warranty covers any and all defects with the product. If your product fails or has problems within the warranty period you can contact our support team by using the Contact Us link. Technical support is limited to the scope of the product itself and not your entire machine.
Damage/Failure due to improper installation, improper usage, failure resulting from an issue with the machine the product is installed on, 3rd party products connected to our product, and/or modification of the product are not covered under warranty.
Question
boburch –
Sold by the meter,
so when ordering multiple meters,
will it will be one piece ?
(0) (0) Watch Unwatch
Tim Hoogland –
If you order more than 1 meter they will be one continuous piece, not individual meter lengths.
(1) (0)
boburch (verified owner) –
I was thinking that’s the way it works.
And was thinking, I should ask just to make sure.
Thank you for the quick reply.
May the Blessing of Jesus Christ be over you and your family.
Bob B.
(0) (0)
Tim Hoogland –
Not a problem at all Bob! Have a great day!
(0) (0)
Question
Mark Thompson –
What is the max operating temperature for these belts?
(0) (0) Watch Unwatch
Tim Hoogland –
These are rated up to 80C max operating temp. Higher than that and the belt may degrade.
(0) (0)
Ken (verified owner) –
Nice belt, real rubber
(0) (0) Watch Unwatch
