EZOut V2 “Pin 27” Board – For use with BLTouch/CRTouch or Filament Sensor – Creality Melzi Boards (V1.1.1, V1.1.2, V1.1.3, V1.1.4, V1.1.5)

Why do you want this upgrade?

If you get the EZOut board you will be using this to connect a BL Touch ABL sensor to your 3D Printer. You plug this board into your LCD header on your control board and then plug the LCD cable into our board. You then have the required 5V, Ground, and Signal pins available to connect to your BL Touch Sensor with ZERO soldering. Recommended BL Touch Installation Information: https://www.thingiverse.com/thing:2975949

Installation Links

EZOut Installation Guide

Use our new Unified 2.0 Firmware and follow our setup guide for the BLTouch here: Unified Firmware – BLTouch Settings

Unified 2.0 for these boards is free from our Help Center.

Bootloader Required

You can add on a bootloader kit above and there is a very easy to follow guide with a video on our page here: 1284p Printer Bootloader Flashing Video Guide – CR-10/Ender 2 3 5/Wanhao i3/Anet

FAQ

• Why is there a pin missing on the header?
  • This is removed so the pin does not connect to the LCD after installation and is completely normal.
• Is a BLTouch Included?
  • No, this is just for our adapter PCB. BLTouch sold separately.
• Is there technical support included?
  • No, due to the low price there is no technical support included unless you add it on at the time of purchase.
