TH3D Upgraded Micro Swiss NG Ducts – 5015/4010 & EZABL Built in – STL Download
$7.00
-
These are improved mounts to provide for direct mounting of our EZABL and EZABL Micro sensors to the NG from Microswiss as well as 5015 fan ducts for better cooling.
This needs to be printed in ABS or the ducts can deform from the hotend heat. If you want/need this printed up in ABS we also have them printed on demand if you need this printed in ABS: https://www.th3dstudio.com/product/th3d-microswiss-ng-fan-ducts-abs-prints/
Description
Print Settings & Material Recommendations
- Layer Height – 0.2mm-0.3mm
- Material – ABS HIGHLY Recommended (Stock ducts are ABS that come on the NG)
- Walls – 3x
- Infill – 50%
- Support – From Build Plate ONLY
- EZABL Sensor Offsets – Located in the download pack in a txt file
Ender 5/Ender 5 Pro/Ender 5 Plus
With the 5015 fan option you will likely need to move the X endstop to the left about 5mm to prevent the fan duct from hitting the printer frame. You will likely also need to change the X bed size in the firmware -5 mm on X and in your slicer.
This is for a DIGITAL DOWNLOAD of the STL file shown in the product pictures above.
How to get your file after purchase
Once your payment clears you will be emailed a link to download the file and if you are logged into your TH3D account it will also show in the “Downloads” section of the “My Account” page. Downloads may be limited to 25 times to prevent account sharing.
License – This is for PERSONAL USE ONLY.
Resale of the file, prints from the file, commercial use, and/or sharing the file online are prohibited. By purchasing this digital download you agree to these terms.
Support – It is up to you to know how to print an STL file. There is no technical support included on any STL file purchases.
Warranty & Refunds – Due to the nature of digital products, all sales are final.
